FIBREGLASS or FRP FLAT PANELS GRP LAMINATES

Eurogrit® flat panels are available in a range of thicknesses (from 3 to 10 mm), depending on the intended use, and various sizes.
They are available with slip resistant or smooth surfaces and are fixed with special fixings or adhesives.

Hand lay-up composite flat panels are made using a combination of chopped strand mat (CSM) and woven roving, incorporating quartz grains for slip resistance. Fibreglass or FRP flat panels are certified to R13 V10 - DIN 51130 slip resistance standards. Standard resin: self-extinguishing isophthalic. Standard colours: Green Ral 6001 and Grey Ral 7004. Tolerances: size ± 5 mm, thickness ± 10%.

TECHNICAL CHARACTERISTICS OF FIBREGLASS LAMINATES
Thickness	Standard sizes	Weight
3 mm	1.0 x 2-3 m 1.2 x 2-3 m 1.5 x 2-3 m	6.5 Kg/m2
5 mm		11.0 Kg/m2
6 mm		13.0 Kg/m2
8 mm		17.3 Kg/m2
10 mm		21.6 Kg/m2

CONCENTRATED LOAD 1% span deflection		Span:
		300 mm	450 mm	600 mm
Thickness:	6 mm	80 daN	40 daN	25 daN
	8 mm	180 daN	90 daN	60 daN
	10 mm	250 daN	140 daN	90 daN



Download the FRP flat panels catalogue as a PDF or ZIP file.



Ask Eurograte for further technical details or a personalised estimate. Contact us NOW!  Tel. +39 02 950911, send us an email or fill in the online form
